The Machine the cylinders and the screw of the above extruders are made of high-quality alloy steel with optimum hardness and strong corrosion resistance after precision finishing and nitrogen treatment.
The Machine the cylinders and the screw of the above extruders are made of high-quality alloy steel with optimum hardness and strong corrosion resistance after precision finishing and nitrogen treatment.
Characteristics:
The Machine the cylinders and the screw of the above extruders are made of high-quality alloy steel with optimum hardness and strong corrosion resistance after precision finishing and nitrogen treatment. The auxiliary machine has a platform working table for making operation easy. The winding unit adopts torque motor to keep proper tension and make winding even and roll-changing easy.
Uses:
It is used for blowing various plastic film of Low Density Polyethylene (LDPE), High Density Polyethylene (HDPE) and Linear Low Density Polyethylene (LLDPE) etc, which are widely used for packing industrial products, garments and food and for covering farmland.
Main Technical Parameter:
Model | FM600 |
Screw Diameter | Φ50mm |
Screw L/D | L/D28:1 |
Screw Speed | 10-100r/min |
Power of Main Motor | 11kw |
Max. Extrusion Output | 50kg/h |
Max. Folding Width of Film | 600mm |
Single-face Thickness of Film | 0.006-0.10mm |
Total Power | 22kw |
Machine Weight | 2200kg |
Overall Dimension(L×W×H) | 4400×2000×4000mm |
Model | FM800 |
Screw Diameter | Φ55mm |
Screw L/D | L/D30:1 |
Screw Speed | 10-120r/min |
Power of Main Motor | 22kw |
Max. Extrusion Output | 40-80kg/h |
Max. Folding Width of Film | 800mm |
Single-face Thickness of Film | 0.008-0.10mm |
Total Power | 36kw |
Machine Weight | 3000kg |
Overall Dimension(L×W×H) | 4800×2800×4300mm |
Model | FM1000 |
Screw Diameter | Φ60mm |
Screw L/D | L/D30:1 |
Screw Speed | 10-120r/min |
Power of Main Motor | 30kw |
Max. Extrusion Output | 50-100kg/h |
Max. Folding Width of Film | 1000mm |
Single-face Thickness of Film | 0.008-0.10mm |
Total Power | 42kw |
Machine Weight | 3500kg |
Overall Dimension(L×W×H) | 5000×3000×4800mm |
